WT-9 Glass turnover table

Name: WT-9 Glass turnover table
Brand: WINTECH GLASS MACHINERY Co.,Ltd.
Availability: InStock
Rating: 5 (1 reviews)

INQUIRY

Description brand introduction

♦ Introduction

It is applied to the connection of single-side edging machine, so that only the two employees can be used to complete the process of glass-to-glass cleaning. The product of the turning machine is mainly suitable for doors and windows, construction, bathroom glass, etc. Tempering plant.This glass edging production line is made up of 4 sets of edging machine, 4 sets of turing table and 1 set of vertical washing machine. Length is about 50.5m, width 1.2m and height 2.5m. From loading glass for edging to finish washing, it only needs two workers for this line through this kind of vertical turning table. And the production line is suitable for processing different sizes of glass continuously.

TECHNICAL SPECIFICATIONS

Technical Specification:

Max.Glass size	2800*2800mm
Min.Glass size	400*400mm
Glass thickness	3-25mm
Transmissinon speed	0.5-6m/min
Land occupation	6300×1500×2700mm
Power	380V/50HZ or Customized

Foshan WINTECH Glass Machinery Co.,Ltd is a science and high-tech glass equipment company Specializing in the various types of glass deep-processing equipments，such as glass bevel edging,glass straight line grinding,glass sandblasting,glass washing,glass drilling,glass cutting, glass purging,glass shape edging,glass mitering,glass double edging,etc.
We always committed to provide the comprehensive service to global glass processers, with glass processing scheme, grinding capacity planning ,glass equipment and consumptive material supply, installation and maintenance. WINTECH is achieve win-win coopertion between platforms.
